Schluter Systems Kerdi Line Shower Grate Assembly (Cover) for Offset and Center Drain Channel Body

Product Features:

• Versatile Installation - It is suitable for wall-adjacent or intermediate positions in showers, allowing flexibility in placement and tile design
• Durable Material - It is made of high-grade brushed stainless steel, ensuring longevity and resistance to corrosion, ideal for wet environments like showers
• Adjustable Frame - It can seamlessly adjust to cover tile or stone from 1/8” to 9/16” thickness, ensuring a perfect flush finish with various flooring materials
• Easy Maintenance - It is designed for easy cleaning and maintenance, the assembly includes a grate that can be removed to access the drain housing
• Designed for use with Schluter KERDI-LINE linear drain channel bodies – compatible with both center and offset drain configurations
• Premium stainless steel construction provides a rust-resistant, long-lasting finish for tiled showers and wet rooms
• Ideal for barrier-free, curbless, walk-in shower installations in both residential and commercial spaces
• Supports installation with porcelain, ceramic, natural stone, or large format tiles
• Integrates seamlessly with Schluter KERDI waterproofing membrane to ensure watertight connection and leak prevention
• Available in a variety of lengths and design finishes to complement modern and minimalist tile layouts
• Sleek linear profile offers enhanced water drainage and stylish appearance
• Frequently used in steam showers, tiled bathrooms, spa rooms, and universal design applications
• Easy to install and fully compatible with Schluter pre-sloped shower trays or mortar bed installations
• Engineered and tested by Schluter Systems for durability, drainage performance, and aesthetic excellence

Product Description:

Schluter-KERDI-LINE is a low profile linear shower drain specifically designed for bonded waterproofing assemblies. KERDI-LINE can be installed adjacent to walls or at intermediate locations in showers, wet rooms, and other applications that require waterproofing and drainage.

Floors can be sloped on a single plane to KERDI-LINE, enabling the use of large-format tiles. Accommodates all common thicknesses of ceramic tiles and stone coverings. Available in lengths ranging from 20 (50 cm) to 72 (180 cm)

The Kerdi-Line grate assembly is designed for use with the Kerdi-Line channel body to create a low profile linear floor drain. Kerdi-Line can be installed next to the wall or in the center of a bonded waterproof assembly. The floor can be sloped on a single plane to Kerdi-Line, which allows for the use of large-format tiles. The grate assembly includes a grate and frame

Schluter-KERDI-LINE is a low profile linear shower drain specifically designed for bonded waterproofing assemblies. KERDI-LINE can be installed adjacent to walls or at intermediate locations. The floor can be sloped on a single plane to KERDI-LINE, which enables the use of large-format tiles and creates interesting design opportunities.

KERDI-LINE consists of a formed stainless steel channel body and grate assembly or covering support to which tile is applied. The channel body features a standard 2" (50 mm) no-hub outlet and is attached to the pipe using an appropriate mechanical (e.g., flexible or no-hub) coupling. The simple connection to standard drain outlets makes KERDI-LINE suitable for new construction and renovation. KERDI-LINE is available with both center and off-set outlets. The off-set outlet is located 8" (20.3 cm) from the edge of the channel body and provides flexibility when obstacles (e.g., floor joists) are encountered during installation. KERDILINE includes a corresponding polystyrene foam channel support to set the drain elevation to the corresponding KERDI-SHOWER-LT/-LTS shower trays. The perimeter of the channel body consists of a bonding flange laminated with a collar made of KERDI. It ensures a simple and secure connection to the bonded waterproofing assembly, both in the floor area and on adjacent walls. KERDI-LINE is available in channel lengths from 20" to 72" (50 cm to 180 cm) in 4" (10 cm) increments. The bonding flange extends approximately 1" (2.5 cm) beyond the channel on all sides.

The KERDI-LINE grate assembly consists of a stainless steel frame that can be seamlessly adjusted to the thickness of the ceramic tile or stone covering – 1/8" to 1" (3 mm to 25 mm) for standard grate assemblies and 1/4" to 23/32" (6 mm to 18 mm) for KERDI-LINE-STYLE grate assemblies – and stainless steel grates that are placed within the frame. The standard grate assembly frame features a 3/8" (10 mm) wide reveal after installation and can be combined with one of two grate options: SOLID (A) or SQUARE (B). Each standard assembly is available in a brushed, chrome, or textured color-coated finish. The SQUARE (B) option is also available with a locking mechanism (brushed stainless steel, 3/4" – 19 mm frame only) for applications where tamper resistance is desired or required (e.g., healthcare and education facilities, etc.). The KERDI-LINE-STYLE grate assembly frame features a minimal reveal after installation and can be combined with one of three grate options: FLORAL (E), CURVE (F), or PURE (G). Each STYLE assembly is available in a brushed finish. The TILE grate (D) consists of a frameless, tileable covering support that is placed flush with the top of the channel body and can therefore accommodate any thickness tile covering. If KERDI-LINE is placed at shower entrance, it is recommended that grate assembly A or the TILE grate is chosen and that the drainage openings span the maximum width of the entrance to limit potential overflow; secondary drainage (e.g., KERDI-DRAIN-F) may be required in the drying area.
